You can construct a rolling light box with as little as:

·     The Honey Sticks System.

·        Two overhead frames.

·        Two roller stands.

·        The Beehive panels from Honey Crates or your preferred covering for the sides of the box.

·        A diffusion rag.

·        A light source, such as a blanket light from Source Maker.

Optional accessories

·        Three-way corners and tubing uprights to join the box in the corners for more rigidity.

·        Two lengths of 1 ¼” speed rail for mounting points on the back of the box

·        Honeycrate LCD

What comes in the box?

Everything you need to suspend a 2’ light box

1. 2 top brackets with 1 1/4” speed rail fittings

2. 2 sliding ears

3. 2 bottom brackets

4. 4 30” lengths of rail

Features

·        T-slot bracket slides on two standard sticks of 1”x1” aluminum square stock, allowing for a perfectly balanced fulcrum between two stands.

·        T-slot offset provides clearance for use on crank stands with large diameter center columns.

·        Dual integrated 1 ¼” speed rail fittings provide the ability to span two parallel lengths of speed rail on the top/back of the box creating the perfect mounting points for lights.

·        The bottom drop out is perfectly sized to let the bottom edge of the Beehive panel drape appropriately maintaining the anti-light leak design.

·        Mild steel with black zinc coating resists oxidation while staying out of reflections.

·        Stainless steel set screws resist oxidation keeping tightening action smooth.

·        Modular design allows any length square stock to be used enabling the use of Honey Sticks with any depth box.

·        Cutouts provide easy pass through for rag ties as well as reducing overall weight.
